Adjustable Pole-Mount Bracket for Solar Panels

Product Information

This adjustable pole-mount bracket is designed for elevated mounting and angle positioning of solar panels and related equipment. The base can be secured to a platform or supporting structure, while the upper mounting plate can be tilted through a pivot mechanism, making it suitable for applications requiring both installation height and positioning flexibility.

Available Model Colors

Available Match Colors

Inquiry

Available Model

Available Match

Adjustable Pole-Mount Solar Panel Bracket Description

This bracket consists of a base mounting plate, vertical support post, upper pivot mechanism, and equipment mounting plate. The structure raises the mounted equipment above the supporting surface while retaining angle-adjustment capability at the upper mounting interface.

The base features multiple mounting holes for fastening to a platform, foundation, or other supporting structure. The vertical post connects the base to the upper assembly, while the pivot mechanism allows the mounting plate to be tilted according to the required equipment position.

The upper mounting plate incorporates both round and elongated holes to accommodate different mounting patterns and installation positions. In addition to solar panels, this type of structure can also be adapted for sensors, monitoring devices, or other equipment requiring elevated and adjustable mounting.

Depending on project requirements, the following features can be customized:

Support post height and profile
Base dimensions and mounting-hole locations
Upper mounting plate dimensions
Round-hole and slot arrangement
Pivot location and structure
Adjustment range
Installation orientation
Component connection method
Surface finishing

Homer Hardware can evaluate stamping, punching, bending, post or tube processing, welding, CNC machining, assembly, and surface finishing based on customer 2D/3D drawings, samples, or installation requirements for customized mounting applications.
